FORSTHOFF - automatic welding machines
Automatic welding machines FORSTHOFF are designed for tarpaulins, tents, awning materials and advertising banners and etc. Welding can be realized through the use of additive materials (welding tape, wire) or via overlaying the basic material. Movable cart speed can be fluently changed to a required level and fluent change of heating temperature can be set as well, which allows to set the exact welding parameters for every single type and thickness of welded material.
| Machine type | FORSTHOFF-P2 | FORSTHOFF-DB | FORSTHOFF-B70 | FORSTHOFF-F | FORSTHOFF-D |
| Technical specification | |||||
| Build-in air supply | |||||
| Welding system | overlaying | welding tape | welding tape | zvárací drôt | overlaying |
| Travel speed (m/min) | up to 18 | up to 11 | up to 11 | up to 19 | up to 11 |
| Tape width / overlaying (mm) | 20; 30; 40; 45 | 50 | 70 | - | 40; 45 |
| Temperature regulation | electronic | electronic | 3-stage | electronic | electronic |
| Temperature range (°C) | 20 - 700 | 20 - 700 | do 700 | 20 - 700 | 20 - 700 |
| Heating element output (W) | 2x2000 | 2x2000 | 2x2000 | 2x2000 | 2x2000 |
| Input voltage (V) | 230 | 230 | 230 | 230 | 230 |
| Plug-in cable (m) | 7 | 7 | 7 | 7 | 7 |
| Weight (kg) | 17,5 | 31,0 | 29,0 | 21,0 | 29,5 |
| Welding nozzles | |||||
| Preplátovacia dýza 20 mm | optional | - | - | - | - |
| Preplátovacia dýza 30 mm | optional | - | - | - | - |
| Preplátovacia dýza 40 mm | optional | - | - | - | optional |
| Preplátovacia dýza 45 mm | optional | - | - | - | optional |
