MUNSCH WEDGE
Plastic sheet laying can be applied in different areas, such an agriculture, construction industry (isolation), environmental protection, in dumping ground, etc. For optimal effect achievement is also necessary to get a high-quality joint. For this purpose are special welding machines designed, which are working on contact heating of welding parts principle via welding wedge and subsequent press. The tightness control can be done via central groove with assistance of testing device Airtest.
Above mentioned way of welding can be used for plastic sheets with thickness from 0,5 mm to 3,0 mm.
| Machine type | WEDGE-IT | WEDGE-IT-LE | WEDGE-IT-MULTI |
| Welding materials | PE, PP, PVC, Hypalon, XR-5 ... | PE, PP, PVC, Hypalon, XR-5 ... | PE, PP, PVC, Hypalon, XR-5 ... |
| Material thickness (mm) | 0,5 - 3,0 | 0,5 - 2,5 | 0,5 - 3,0 |
| Travel speed (m/min) | 0 - 6 | 0 - 4 | 0 - 4,3 |
| Max. welding wedge temperature (°C) | 505 | 505 | 505 |
| Temperature regulation | |||
| Output (W) | 1600 | 1350 | 2000 |
| Input voltage (V) | 110 or 230 | 110 or 230 | 110 or 230 |
| Data shown on display | temperature, speed | temperature, speed | temperature, speed |
| Total weight (kg) | 24 | 13 | 11 |
